Reasons to choose us：
● New Generation iTech Welding Equipments
● Intelligent After Sales Service
● MMA / TIG DC LIFT
● Excellent Smooth and Stable Welding Performance.
● VRD Optional.Anti-sticking, Hot start, Arc force of the big pipe and tank.
● High Duty Cycle
● Good performance
● Good for use With Long Supply Cables
● Handle and Shoulder Strap|(optional)Makes it Very Portable
● All Types of Mains Power Network or Power Generator compatible
● RIGHT 3 Years Limited Warranty for Parts and Labor
|
Models/Parameters |
RIGHT ARC - 160 |
RIGHT ARC - 200 |
||
|
Input power |
Single phase, 230V±10% |
Single phase, 230V±10% |
||
|
|
50/60Hz |
50/60Hz |
||
|
Rated input current(A) |
32 |
44 |
||
|
Rated input power(KW) |
5.6 |
10.1 |
||
|
Power factor |
0.8 |
0.8 |
||
|
Welding current range(A) |
10~160 |
10~200 |
||
|
Max no-load voltage(V) |
62 |
64 |
||
|
Efficiency |
≥80% |
≥80% |
||
|
Duty cycle(40℃,10 minuters) |
||||
|
160A/25% |
200A/25% |
|||
|
80A/100% |
100A/100% |
|||
|
Protection class |
IP23 |
IP23 |
||
|
Insulation class |
F |
H |
||
|
Dimensions of Machine L × W × H in mm |
380×140×260 |
420×140×260 |
||
|
Weight(Kg) |
6 |
7 |
||
|
Standards |
IEC 60 974-1;-10 |
IEC 60 974-1;-10 |
||
|
|
EN60974-10 |
EN60974-10 |
||
Outstanding welding performance is no overstatement. Every element of RIGHT iTECH INVERTERS are
desingned to meet the needs of professional welders on the move. Where size, weight and welding qulity are
concerned, there is no equal. RIGHT iTECH INVERTERS can be used with mains power supplies or power
generators even with extra long supply cables,
Light and easy transportable: The machines are easy to carry, in hand for all type of job.
Large voltage reserves and automatic arc force control provide excellent arc stability in all welding positions
and for a wide range of electrode types.
The large and clear meter display makes accurate current setting simple and easy, and precise lift TIG igniton
ensures high quality DC TIG welding.
Intelligent protection:Over-voltage, Low-voltage, Over-current, Over-heat
ideal for maintenance, building construction and light metal structures
